COMMUNICA
TION INTER
FACE
191
Note
F
or USB, the baud rate
should be fixed to 115,200.
7.
Click o
n the
Send
tab.
In the
EOL
configurati
on, check on the
+LF
check boxes.
Enter the query:
*idn?
Click on
Send A
SCII
.
190
192
