GW Instek ASR-3000 Series - Page 207

APPENDIX
207
AC+DC-SYNC Mode
ASR-3200
ASR-3300
ASR-3400
ASR-3400HF
Range
100V
Wave Shape
SIN
ACV
0.0 Vrms
DCV
+0.0 Vdc
SIG
LINE
IRMS
21.00 A
31.50 A
42.00 A
V Limit
+/- 285.0 V
F Limit Hi
999.9 Hz
5000 Hz
IPK Limit
+/- 126.0 A
+/- 189.0 A
+/- 252.0 A
+/- 168.0 A
ON Phs
0.0
o
OFF Phs
0.0
o
Syn Phs
0.0
o
AC-SYNC Mode
ASR-3200
ASR-3300
ASR-3400
ASR-3400HF
Range
100V
Wave Shape
SIN
GAIN
100.0
IRMS
21.00 A
31.50 A
42.00 A
V Limit
200.0 Vrms
F Limit
999.9 Hz
5000 Hz
IPK Limit
+/- 126.0 A
+/- 189.0 A
+/- 252.0 A
+/- 168.0 A
ON Phs
0.0
o
OFF Phs
0.0
o
Syn Phs
0.0
o
AC-VCA Mode
ASR-3200
ASR-3300
ASR-3400
ASR-3400HF
Range
100V
Wave Shape
SIN
GAIN
100.0
IRMS
21.00 A
31.50 A
42.00 A
V Limit
200.0 Vrms
F Limit
999.9 Hz
5000 Hz
IPK Limit
+/- 126.0 A
+/- 189.0 A
+/- 252.0 A
+/- 168.0 A
ON Phs
0.0
o
OFF Phs
0.0
o
Menu
ASR-3000
T ipeak, hold(msec)
1 ms
IPK CLR
EXEC
Power ON
OFF
