GW Instek ASR-3000 Series User Manual

APPENDIX
223
Weight
Approx. 25 kg
Accessories
Safety
information
1 copy
CO-ROM
1 disc
Input/Ouput
Cover
1 set
EIA Rack Mount
1 set
USB Cable
1 piece
External Signal Input (AC+DC-EXT, AC-EXT Mode)
Specification
Factory Default
Gain setting range
100 V range: 0.0 to 285.0 times
100
200 V range: 0.0 to 570.0 times
200
Input terminal
BNC connector
Input impedance
1 MΩ
Input voltage range
±2.5 V (A/D resolution 12 bit)
Nondestructive maximum
input voltage
±10 V
Gain resolution
0.1 times
Accuracy
±5 %
(DC, or 45Hz ~ 65 Hz, gain is at initial value, with
rate voltage output, no load)
EXT: Output voltage (V) = External signal input (V) x Gain (V/V)
Voltage Setting Signal Input (AC-VCA Mode)
Specification
Factory Default
Gain setting range
100 V range: 0.0 to 250.0 times
100
200 V range: 0.0 to 500.0 times
200
Input terminal
BNC connector
Input impedance
1 MΩ
Input voltage range
DC 0 ~ 2.5 V
Nondestructive maximum
input voltage
±10 V
Accuracy
±5 %
