H3C MSR Series Configuration Guide

57
1. If the source MAC address does not match any entry in the white list, the frame is dropped. If
there is a match, the frame is considered valid and is processed further.
2. If no white list entries exist, the static and dynamic blacklists are searched.
3. If the source MAC address matches an entry in any of the two lists, the frame is dropped.
4. If there is no match, or no blacklist entries exist, the frame is considered valid and is processed
further.
Figure 25 Frame filtering
If client 1 is present in the backlist, it cannot associate with the fat AP. If it is only in the white list, it can
get associated with the fat AP.
Hardware compatibility with WLAN
WLAN IDS is not available on the following routers:
• MSR 2600.
• MSR 30-11.
• MSR 30-11E.
• MSR 30-11F.
• MSR3600-51F.
WLAN IDS configuration task list
Task Description
Configuring AP operating mode Required.
Configuring attack detection
Configuring attack detection.
Optional.
Displaying and maintaining attack
detection.
Configuring blacklist and whitelist Optional.

H3C MSR Series Specifications

General

Category	Network Router
IPv6 Support	Yes
Dimensions	Varies by model
Weight	Varies by model
Product Type	Modular Router
Ports	Varies by model
WAN Interfaces	Varies by model
Firewall	Yes
QoS	Yes
Wireless Support	Varies by model
USB Ports	Varies by model
Console Port	Yes
Power Supply	Varies by model
Redundancy	Varies by model
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% non-condensing
Series	MSR
Certifications	CE, FCC, RoHS
