H3C S5560S-EI Series User Manual

1-3
Item S5560S-28P-EI S5560S-52P-EI S5560S-28S-EI S5560S-52S-EI
• Max voltage: –36 VDC to –72 VDC
DC power source for the PSR150-D1 power supply: –48 VDC power source in the
equipment room or an RPS (H3C RPS800-A or RPS1600-A)
Minimum
power
consumption
• Single
PSR75-12A
input: 12 W
• Single
PSR150-A1
input: 15 W
• Single
PSR150-D1
input: 15 W
• Dual
PSR75-12A
inputs: 13 W
• Dual
PSR150-A1
inputs: 20 W
• Dual
PSR150-D1
inputs: 21 W
• Single
PSR75-12A
input: 21 W
• Single
PSR150-A1
input: 24 W
• Single
PSR150-D1
input: 25 W
• Dual
PSR75-12A
inputs: 23 W
• Dual
PSR150-A1
inputs: 29 W
• Dual
PSR150-D1
inputs: 30 W
• Single
PSR75-12A
input: 12 W
• Single
PSR150-A1
input: 16 W
• Single
PSR150-D1
input: 15 W
• Dual
PSR75-12A
inputs: 14 W
• Dual
PSR150-A1
inputs: 22 W
• Dual
PSR150-D1
inputs: 21 W
• Single
PSR75-12A
input: 21 W
• Single
PSR150-A1
input: 25 W
• Single
PSR150-D1
input: 26 W
• Dual
PSR75-12A
inputs: 24 W
• Dual
PSR150-A1
inputs: 30 W
• Dual
PSR150-D1
inputs: 32 W
Maximum
power
consumption
• Single
PSR75-12A
input: 29 W
• Single
PSR150-A1
input: 32 W
• Single
PSR150-D1
input: 35 W
• Dual
PSR75-12A
inputs: 32 W
• Dual
PSR150-A1
inputs: 39 W
• Dual
PSR150-D1
inputs: 44 W
• Single
PSR75-12A
input: 44 W
• Single
PSR150-A1
input: 46 W
• Single
PSR150-D1
input: 57 W
• Dual
PSR75-12A
inputs: 46 W
• Dual
PSR150-A1
inputs: 52 W
• Dual
PSR150-D1
inputs: 59 W
• Single
PSR75-12A
input: 33 W
• Single
PSR150-A1
input: 35 W
• Single
PSR150-D1
input: 40 W
• Dual
PSR75-12A
inputs: 36 W
• Dual
PSR150-A1
inputs: 42 W
• Dual
PSR150-D1
inputs: 47 W
• Single
PSR75-12A
input: 47 W
• Single
PSR150-A1
input: 49 W
• Single
PSR150-D1
input: 58 W
• Dual
PSR75-12A
inputs: 49 W
• Dual
PSR150-A1
inputs: 56 W
• Dual
PSR150-D1
inputs: 60 W
Chassis
leakage
current
compliance
UL 62368-1/EN 62368-1/IEC 62368-1/UL 60950-1/EN 60950-1/IEC 60950-1/GB4943.1
Melting
current of
power supply
fuse
• PSR75-12A: 3.15 A, 250 V
• PSR150-A1: 6.3 A, 250 V
• PSR150-D1: 8 A, 250 V
Operating
temperature
–5°C to +45°C (23°F to 113°F)
Relative
humidity
5% to 95%, noncondensing
Fire
resistance
compliance
UL 62368-1/EN 62368-1/IEC 62368-1/UL 60950-1/EN 60950-1/IEC 60950-1/GB4943.1
