H3C S5560S-EI Series User Manual

1-5
Item S5560S-28F-EI S5560S-52F-EI
Melting current of power
supply fuse
• PSR75-12A: 3.15 A, 250 V
• PSR150-A1: 6.3 A, 250 V
• PSR150-D1: 8 A, 250 V
Operating temperature –5°C to +45°C (23°F to 113°F)
Relative humidity 5% to 95%, noncondensing
Fire resistance
compliance
UL 62368-1/EN 62368-1/IEC 62368-1/UL 60950-1/EN 60950-1/IEC
60950-1/GB4943.1
Table1-4 Technical specifications for PoE switches of the S5560S-EI series
Item S5560S-28S-PWR-EI S5560S-52S-PWR-EI
Dimensions
(H × W × D)
43.6 × 440 × 460 mm (1.72 × 17.32 × 18.11 in)
Weight ≤ 8.5 kg (18.74 lb) ≤ 9.5 kg (20.94 lb)
Console port
• 1 × Micro USB console port
• 1 × serial console port
Only the Micro USB console port is available when you connect both ports.
USB port 1 1
Management
Ethernet port
1 1
10/100/1000
BASE-T
autosensing
Ethernet port
24 (The rightmost four ports and their
corresponding SFP ports form combo
interfaces.)
48
SFP port
4 (The four ports and their corresponding
10/100/1000BASE-T autosensing Ethernet
ports form combo interfaces.)
N/A
SFP+ port 4
Power supply
slot
2, on the rear panel
Input voltage
PSR180-56A:
• Rated voltage:
 100 VAC to 240 VAC @ 50 or 60 Hz
 240 VDC
• Max voltage:
 85 VAC to 290 VAC @ 47 to 63 Hz
 180 VDC to 320 VDC
PSR360-56A/PSR720-56A:
• Rated voltage: 100 VAC to 240 VAC @ 50 or 60 Hz
• Max voltage: 90 VAC to 264 VAC @ 47 to 63 Hz
PSR1110-56A:
• Rated voltage: 115 VAC to 240 VAC @ 50 or 60 Hz
• Max voltage: 102.5 VAC to 264 VAC @ 47 to 63 Hz
PSR560-56D:
• Rated voltage: –48 VDC to –60 VDC
• Max voltage: –36 VDC to –72 VDC
DC power source: –48 VDC power source in the equipment room or an RPS (H3C
