H3C S5560X-EI Series User Manual

7
Installation accessories
Table 4 Installation accessories for the S5560X-EI switches
Switch model
Front mounting brackets
(Figure 4)
Rear mou
nting brackets and
shoulder screws (Figure 5)
S5560X-30C-EI
S5560X-54C-EI
S5560X-30F-EI
S5560X-54F-EI
S5560X-34S-EI
S5560X-54S-EI
Provided N/A
S5560X-30C-PWR-EI
S5560X-54C-PWR-EI
Provided Provided
Figure 4 Front mounting bracket
(1) Screw hole for attaching the bracket to the switch (2) Screw hole for attaching the bracket to the rack
(3) M4 screw
Figure 5 Rear mounting bracket and shoulder screw
(1) Screw hole for attaching the bracket to the rack (2) Shoulder screw
1
2
3
