NOTE:
The PSR1110-56A power module adds 64 mm (2.52 in) to the total depth of the switch, which
includes the power module handle.
Hot-swappable fan trays
S5560X-EI switches except the S5560X-34S-EI and S5560X-54S-EI support the LSPM1FANSA and
LSPM1FANSB fan trays.
Table 16 Hot-swappable fan trays
Item Specifications
LSPM1FANSA fan tray
Dimensions 40 × 40 × 104 mm (1.57 × 1.57 × 4.09 in)
Fan speed 20000 R.P.M
Max airflow 20 CFM
Airflow direction Back to front (from the power module side to the network port side)
Input voltage 12 V
Maximum power consumption 9.8 W
Reference
H3C LSPM1FANSA & LSPM1FANSB Fan Trays User Guide
LSPM1FANSB fan tray
Dimensions 40 × 40 × 104 mm (1.57 × 1.57 × 4.09 in)
Fan speed 20000 R.P.M
Max airflow 20 CFM
Airflow direction Front to back (from the network port side to the power module side)
Input voltage 12 V
Maximum power consumption 9.8 W
Reference
H3C LSPM1FANSA & LSPM1FANSB Fan Trays User Guide
Expansion cards
S5560X-EI switches except the S5560X-34S-EI and S5560X-54S-EI each provide an expansion slot
at the rear. Select expansion cards for the switches as required.
Table 17 Expansion cards
Item Specifications
LSWM2QP2P
Description 2-port 40GE QSFP+ interface card
Port type and quantity 2 × 40 Gbps QSFP+ fiber ports
Available transceiver modules
and cables
See Table 30, Table 31, and Table 32.
