7
Figure 8 S9850-4C chassis dimensions (mounting brackets installed at the power module
side, left-side view)
(1) Cable management bracket (2) Power module handle
(3) Mounting bracket
Figure 9 S9850-32H chassis dimensions (mounting brackets installed at the port side,
left-side view)
(1) Power module handle (2) Mounting bracket
Figure 10 S9850-32H chassis dimensions (mounting brackets installed at the power module
side, left-side view)
(1) Power module handle (2) Mounting bracket
88.1 mm
(3.47 in)
26 mm (1.02 in)
660 mm
(25.98 in)
90 mm
(3.54 in)
2
1
3
