Configuring LSI-9500 series storage
controllers
The BIOS screens might vary by the BIOS version.
The screenshots in this chapter are for
About the LSI-9500 series storage controllers
The LSI-9500 series storage controllers support 12-Gbps data channels. For detailed storage
controller information, access http://www.h3c.com/en/home/qr/default.htm?id=66
.
The LSI-9500 series storage controllers contain the following models:
HBA-LSI-9500-8i
HBA-LSI-9500-16i
The storage controller does not support configuring RAID arrays.
Configuring controller settings in UEFI mode
This section describes how to configure the storage controller in UEFI mode. For more information
about how to enter the BIOS and set the boot mode to UEFI, see the BIOS user guide for the
server.
Controller configuration tasks at a glance
To configure controller settings in UEFI mode, perform the following tasks:
Refreshing configuration information
(Optional.) Viewing basic controller information
(Optional.) Viewing drive information
(Optional.) Locating drives
(Optional.) Configuring boot options for the legacy mode
Refreshing configuration information
1. Access the BIOS setup screen. During server POST, press Delete, Esc, or F2 as prompted to
open the BIOS setup screen as shown in Figure 1.
For how to navigate screens and modify settings, see the operation instructions at the lower
right corner.
