11
INSTALLATION
June 1999
96-8000
UNPACKING THE VMC
UNCRATING
NOTE: Unless you are certain that you will not be shipping the machine, the crate and
packing materials should be stored for reuse. Be careful not to damage the
crate and the other packing materials.
CAUTION! Use extreme caution not to damage the pressurized hydraulic counterbalance
when removing the machine from it's container.
1. Pry off the clips around the top of the crate with a claw hammer and remove the top panel.
2. Pry off all but one clip at each corner of the crate.
3. Remove plastic cover.
CAUTION! Do not put undue pressure on the top of the machine as you remove the
plastic.
4. Pry off the last clip at each corner and remove the side panels.
CAUTION! The side panels are heavy îš— be careful that they do not drop on your feet or
tip over on you.
5. Remove the coolant tank and the cleats that held them in place.
