271
PARAMETERS
June 1999
96-8000
9. PARAMETERS
Parameters are seldom-modified values that change the operation of the machine. These include servo motor
types, gear ratios, speeds, stored stroke limits, lead screw compensations, motor control delays and macro
call selections. These are all rarely changed by the user and should be protected from being changed by the
parameter lock setting. If you need to change parameters, contact HAAS or your dealer. Parameters are
protected from being changed by Setting 7.
The Settings page lists some parameters that the user may need to change during normal operation and these
are simply called "Settings". Under normal conditions, the parameter displays should not be modified. A
complete list of the parameters is provided here.
The PAGE UP, PAGE DOWN, up and down cursor keys , and the jog handle can be used to scroll through the
parameter display screens in the control. The left and right cursor keys are used to scroll through the bits in a
single parameter.
PARAMETER L IST
Parameter 1 X SWITCHES
Parameter 1 is a collection of single-bit flags used to turn servo related functions on and off.
The left and right cursor arrows are used to select the function being changed. All values are 0
or 1 only. The function names are:
REV ENCODER Used to reverse the direction of encoder data.
REV POWER Used to reverse direction of power to motor.
REV PHASING Used to reverse motor phasing.
DISABLED Used to disable any axis.
Z CH ONLY With A only, indicates that no home switch.
AIR BRAKE With A only, indicates that air brake is used.
DISABLE Z T Disables encoder Z test (for testing only).
SERVO HIST Graph of servo error (for diagnostics only).
INV HOME SW Inverted home switch (N.C. switch).
INV Z CH Inverted Z channel (normally high).
CIRC. WRAP. (Future Option - Not Yet Implemented) With A only, causes 360
wrap to return to 0.
NO I IN BRAK With A only, removes I feedback when brake is active.
LOW PASS +1X Adds 1 term to low pass filter.
LOW PASS +2X Adds two terms to low pass filter.
OVER TEMP NC Selects a normally closed overheat sensor in motor.
CABLE TEST Enables test of encoder signals and cabling.
