96-8000 415
OPTIONS
June 1999
Parameter 312 CAROUSEL BUMP TIME
This parameter supports the serpentine type 1 and the Disk type 1 tool changers. During tool change
recovery, the carousel may be moved a small amount by pressing the ATC FWD or ATC REV key. Each
press of the key will cause the carousel motors to run for the amount of time (in milliseconds) specified by
this parameter. For vertical mills without a serpentine type 1 or Disk type 1 side- mount tool changer, this
parameter should be set to 0.
ALARMS
Alarm 622 TOOL ARM FAULT
This alarm supports the serpentine type 1 and the Disk type 1 tool changers. It is generated if the arm is
not at the Origin position, or the arm motor is already on when a tool change process is started.
Alarm 623 SIDE MOUNT CAROUSEL ERROR
This alarm supports the serpentine type 1 and the Disk type 1 tool changers. It is generated if the carousel
motor is still on when the tool pocket is unlocked and lowered prior to a tool change.
On the serpentine type 1 tool changer, during tool change recovery, this alarm is also generated if the
carousel does not start to rotate after the allowed time specified by parameter 60 TURRET START DELAY,
or does not stop rotating after the allowed time specified by parameter 61 TURRET STOP DELAY.
Alarm 624 INVALID TOOL
This alarm supports the serpentine type 1 and the Disk type 1 tool changers. It is generated if the tool
specified by the G-code program is not found in the POCKET- TOOL table.
Alarm 625 INVALID TC START CONDITION
This alarm supports the serpentine type 1 and the Disk type 1 tool changers. It is generated if conditions
are not correct when a tool change is started. Incorrect conditions include:
îš• Tool not found in POCKET- TOOL table
îš• Unable to move carousel to specified tool
îš• Shot pin not engaged (serpentine type 1).
îš• Tool carousel not at TC mark (Disk type 1).
îš• Arm not in Origin position.
îš• Arm motor already on.
Alarm 626 TOOL POCKET SLIDE ERROR
This alarm supports the serpentine type 1 and the Disk type 1 tool changers. It is generated if the tool
pocket has not moved to its commanded position (and settled) within the time allowed by parameters 306
and 62. This alarm can also be generated if the tool changer is in an invalid position at power- up, the start
of a gear change or tool change.
Alarm 627 ATC ARM POSITION TIMEOUT
This alarm supports the serpentine type 1 and the Disk type 1 tool changers. It is generated if the tool arm
has not moved after the allowed time or has not stopped after the allowed time. Refer to Parameter 309
MOTOR COAST TIME.
Alarm 628 ATC ARM POSITIONING ERROR
This alarm supports the serpentine type 1 and the Disk type 1 tool changers. It is generated if:
îš• The arm was being moved from the ORIGIN position to the CLAMP position and it coasted past
the MOTOR STOP point or could not get to the CLAMP point.
îš• The arm was being moved from the CLAMP position to the UNCLAMP position and it coasted
past the MOTOR STOP point or could not get to the UNCLAMP point (same physical point as
CLAMP).
îš• The arm was being moved back to the ORIGIN position and it coasted past the MOTOR STOP
point or could not get to the ORIGIN point.
