122
OPERATION
96-8000
June 1999
MESSAGES
The screen will ALWAYS show some of the current conditions selected in the control. These are fixed status
displays that describe the condition of the machine. The following conditions are displayed on the screen:
The selected display in the top left corner,
The selected mode in parentheses,
The presently selected program in the top right corner,
The most recent line number in the top right corner,
Up to 18 lines of variable display data,
Any of the following conditions that apply:
ALARM Blinking in lower right corner when alarm occurs.
BLKDEL BLOCK DELETE is turned on.
BUF When next block is ready in continuous path.
DOOR HOLD An open door has stopped the program.
DRYRUN DRY RUN is selected.
DWELL When a G04 is being performed.
FEED When a feed motion is in progress.
FEED % Feed rate override is active.
FEED HOLD FEED HOLD is active.
OPTSTP OPTIONAL STOP is turned on.
RAPID % Rapid override is active.
RUNNING When a program is running.
SINGBK SINGLE BLOCK is turned on.
SINGBK STOP When a program is stopped in SINGLE BLOCK.
SPIND % Spindle speed override is active.
TOOL UNCLP Reverse video when the tool is unclamped.
XYZA-MIR These axes are set to mirror image.
The following error messages are received when the wrong button is pressed.
ALARM ON Cannot start an operation until alarms are reset.
ALTER The selected text can now be altered.
AUX AXIS BUSY One or more auxiliary axes are busy in an operation.
BAD CODE Code entered is not understood.
BAD FILE NAME Not a valid file name.
BAD NAME Name entered is not Onnnnn.
BLOCK TOO LONG Block being edited would be too long.
CAN NOT COPY The selected program can not be copied.
CAN'T RENAME The selected program cannot be renamed.
CAN'T UNDO! The last function can not be undone.
CNVEYR DISABLED Chip conveyor has been disabled by parameters.
COOLANT OFF Coolant pump is off.
COOLANT ON Coolant pump is on.
DEL ALL (Y/N) ? Delete all, yes or no ?
DELETE Deleting text as requested.
DIR FULL Maximum number of programs exceeded.
DIR NOT FOUND Directory of floppy disk not found.
DISABLED AXIS Requested axis has been disabled, and cannot be jogged.
DISK NOT IN DRV No disk in floppy drive.
DISK NOT RDABLE Floppy disk cannot be read by control.
DISK WRT PROTECT Cannot save to floppy disk, it is write protected.
