PROGRAMMING EXAMPLES
96-8000
June 1999
PROGRAM CODE FOR MIRROR IMAGE IN X-AXIS:
PROGRAM EXAMPLE DESCRIPTION
%
O3600 (Mirror image X-axis)
T1 M06 (Tool #1 is a .250 diameter end mill)
G00 G90 G54 X-.4653 Y.052 S5000 M03
G43 H01 Z.1 M08
G01 Z-.25 F5.
F20.
M98 P3601
G00 Z.1
G101 X0.
X-.4653 Y.052
G01 Z-.25 F5.
F20.
M98 P3601
G00 Z.1
G100 X0.
G28 G91 Y0 Z0
M30
%
%
O3601 (Contour subprogram)
G01 X-1.2153 Y.552
G03 X-1.3059 Y.528 R.0625
G01 X-1.5559 Y.028
G03 X-1.5559 Y-.028 R.0625
G01 X-1.3059 Y-.528
G03 X-1.2153 Y-.552 R.0625
G01 X-.4653 Y-.052
G03 X-.4653 Y.052 R.0625
M99
%
