Haas VF-1

TECHNICAL REFERENCE
475
June 1999
96-8000
# Name # Name
1009 Pallet Clamped SW 1121 PAL Clamp
1021 APC Door 1122 Door
1022 APC Pin CLR #1 1125 APC Motor
1023 APC Pin CLR #2 1126 Beeper
1026 APC PAL #2 Home
1027 APC PAL #1 Home
The second page of diagnostic data is displayed using the PAGE UP and PAGE DOWN keys. It contains:
INPUTS 2
Name Name Name
X Axis Z Channel X Overheat X Cable Input
Y Axis Z Channel Y Overheat Y Cable Input
Z Axis Z Channel Z Overheat Z Cable Input
A Axis Z Channel A Overheat A Cable Input
B Axis Z Channel B Overheat B Cable Input
X Home Switch X Drive Fault Spindle Z Channel
Y Home Switch Y Drive Fault
Z Home Switch Z Drive Fault
A Home Switch A Drive Fault
B Home Switch B Drive Fault
The following inputs and outputs pertain to the Haas Vector Drive. If it is not enabled, these will display a value
of *. Otherwise, it will display a 1 or 0.
Spindle Forward
Spindle Reverse
Spindle Lock
Spindle at Speed*
Spindle Stopped
Spindle Fault
Spindle is Locked
Spindle Over heat
Spindle Cable Fault
