Haas VF-1 User Manual

71
INSTALLATION
June 1999
96-8000
3. Attach the lifting chains and hooks to the lifting points, with the rigging beam, spreader bar, and
spacer block in place. Position the spreader bar so the lifting chains do not come into contact
with the waycovers.
Fig. 3-3 VF-6/8 lifting positions.
4. Use the spacer block to keep the chains from damaging the rear conduit lines.
* On machines with eyebolt through holes, reinstall the hole plugs.
5. The following weight specifications are an approximation of weight distribution and chain length
required to lift the machines.
enihcaM)sdnuop(thgieWhtgneLniahC
)nmuloc(
E/O-FV
TXE/EO-FV
1-FV
2-FV
3-FV
4-FV
04/5-FV
05/5-FV
6-FV
7-FV
8-FV
9-FV
01-FV
11-FV
000,7
009,7
001,7
000,8
005,21
003,31
005,41
006,41
000,12
000,32
000,42
000,52
000,82
004,92
-
-
-
-
-
-
-
-
"021
"021
"021
"021
"021
"021
