hager hw+ User Manual

12 6LE008146B
The sentinel Energy trip unit
2.2 Hager Power setup software
Principal functions
Display the functional state of the circuit breaker, maintenance information and principal
technical characteristics.
Perform a commissioning by importing settings from Hagercad.
Generate and export a PDF of the test reports and commissioning reports.
Perform a test of the trip curve resulting from the protection parameter settings of the hw+
circuit breakers.
Perform a forced electro-mechanical tripping of the circuit breakers.
Display and modify all the electronic trip unit parameter settings.
Display alarms in progress.
Download and export the electronic trip unit settings in a file in CSV format.
Save the settings of a circuit breaker from within the Energy family to load them into one or
more similar circuit breakers.
Force the opening or closing of the OAC, PTA and ZSI output contacts.
Display the active alarms.
View the event logs and export them in a file in CSV format.
Display the status of the operating counters available (handling cycles, tripping operations...).
Perform the remote control actions (opening, closing, switching of protection profiles,
inhibition of advanced protections) in a safe way.
Manage the passwords of the Energy trip unit, the communication modules and the panel
display.
The Hager Power setup software is available on the Hager website for your country.
IT configuration required.
Minimal Recommended
Operating
system
Windows 10 x32 bits Windows 10 x64 bits
Memory 4 Gb RAM 8 Gb RAM
Disk space 50 Mb 50 Mb
Components
Microsoft .NET Framework 4.7.2
.NET Core Runtime 3.1.13
.NET Desktop Runtime 3.1.13
Microsoft web view 2
v1.0.818.14
Microsoft .NET Framework 4.7.2 or
higher
.NET Core Runtime 3.1.13
or higher
.NET Desktop Runtime 3.1.13 or higher
Microsoft web view 2 v1.0.818.14 or
higher
Resolution 1024x768 pixels 1280x1024 pixels
