hager hw+ - 3.6 Protection menu

296LE008146B
Navigation and menus
3.6 Protection menu
Submenus Parameter Unit Description
LONG TIME
Ir x In 0.40xIn to 1.00xIn, in increments of 0.01; default value 0.40xIn
tr s 0.5 to 25s in increments of 0.5 s; default value 0.5s
Curve - Thi/HVF I4t/EI I2t/VI It/SI I0.02t; default value Thi
SHORT TIME
Activation - On/O; default value On.
Isd x Ir 1.0 to 10xIr in increments of 0.5; default value 1.5xIr
tsd ms 50 to 600 ms in increments of 50; default value 100ms
I²t - On/O; default value O
ZSI STD - On/O; default value O
INSTANTA-
NEOUS
Activation - On/O; default value On
Ii x In 1.5xln to 15xIn, in increments of 0.5; default value 1.5xln
EARTH
Activation - On/O; default value O for 3-pole, On for 4-pole
Ig x In 0.1 to 1.0xIn in increments of 0.1; default value 0.2xIn
tg ms 50 to 600 with steps of 50
I²t - On/O; default value O
ZSI GF - On/O; default value O
NEUTRAL
Activation - On/O; default value O for 3-pole and On for 4-pole
IN / Ir (%) % Ir
50 to 200%Ir, in increments of 50; default value 100%Ir for a 4-pole
circuit breaker
Content of the PROTECTION menu
