3.11 Information menu
Submenus Text Unit Description
STATUS
PROT. PROFILE - A or B
FS CONTACT - O or On
ON/OFF
COUNTER
- Number of openings/closures
TRIP NUMBER - Number of trips
OPERAT. TIME h Cumulative operating time (hours).
SETTINGS - Date last settings saved
LAST MAINT. - Date of the last maintenance
MAINT. TYPE - Maintenance type
NEXT MAINT. - Date of the next maintenance
ALARM LIST - - -
ALARM HISTORY - - -
TRIP HISTORY - - -
COM STATUS
BLUETOOTH - On or O
MODBUS RTU - On or O
MODBUS TCP - On or O
IDENTIFICATION
RANGE NAME - hw+
FRAME - HW1
In A 400 to 1600 A
Icu kA 2 kA, 55 kA, 66 kA
FRAME - HW2
In A 630 to 2500 A
Icu kA 55 kA, 66 kA, 100 kA
FRAME - HW4
In A 1000 to 4000 A
Icu kA 66 kA, 85 kA, 120 kA
FRAME - HW6
In A 3200 to 6300 A
Icu kA 100 kA
SERIAL NUMBER - Serial number
PRODUCT CODE - Product code
DESCRIPTION - -
TU TYPE - LSI / LSIG
OPTION Basic, Meter Plus, Harmonic, Advanced, Ultimate
TU SN - Trip unit serial number
Content of the INFORMATION menu
