The sentinel Energy trip unit
2.3 Hager Power touch application
The Hager Power touch mobile application displays status, measurement and settings
information, and allows the circuit breaker to be remotely controlled in order to perform an
opening or closing command.
It is compatible with the hw+ circuit breakers with the sentinel Energy trip unit.
This application is particularly useful for day-to-day operation and maintenance.
The Energy trip unit must be powered for it to establish the Bluetooth connection. Only one
smartphone can be connected to a circuit breaker at a time.
The Hager Power touch mobile application allows access to a Home page showing the circuit
breaker's principal characteristics, its operating state and maintenance information.
The other information and functions are described in the sections below:
Remote com-
mand
Close/open
allows the circuit breaker's opening or closing functions to be carried out.
Voltage and
current
...
displays real-time voltage and current values.
Quality of l...
Frequency,
power fac...
displays frequency, power factor, harmonic distortion rate and individual harmonic
values.
Demand
Current and
power
displays the current demand and power demand values.
Power...
+Quadrant, phase
rotation...
display the power and real-time energy measurement values as well as the power
quadrant and phase sequence.
Parameters
Overview of...
gives a read-only view of the values of the protection setting, advanced protections,
alarms, electrical grid and the date and time of the circuit breaker.
History
Overview of all
events
display the events history by section.
