196LE008146B
Navigation and menus
3.2 Navigation in the tree
Navigation in the tree is done from the main menus screen.
When navigating through the tree structure, the following actions can be performed:
• Display and modification of the standard protection settings
• Display and modification of the advanced protection settings
• Display of measured values
• Display and modification of the alarm settings
• Display and modification of the configuration settings
• Display of information
• Access the control functions of the MODE menu.
PROTECTION
Button Description
Returns you to the main menu
Enters the tree of the main menu selected.
Navigates between submenus
Moves through the content of the submenu
Navigation between submenus
