30 6LE008146B
Navigation and menus
3.7 Advanced Protection menu
Submenus Text Unit Description
UV-27
CONFIG - O, Trip, Alarm
INHIBIT - O or On
U-V TYPE - L-L or L-N
THRESHOLD V 100 to 1000 V in increments of 5 V
TIME s 0.1 to 300 with steps of 0.1
OV-59
CONFIG - O, Trip, Alarm
INHIBIT - O or On
U-V TYPE - L-L or L-N
THRESHOLD V 100 to 1000 V in increments of 5
TIME s 0.1 to 300 with steps of 0.1
UF-81L
CONFIG - O, Trip, Alarm
INHIBIT - O or On
THRESHOLD Hz 45 to Fn with steps of 0.1
TIME s 0.1 to 300 with steps of 0.1
OF-81H
CONFIG - O, Trip, Alarm
INHIBIT - O or On
THRESHOLD Hz Fn to 65 with steps of 0.1
TIME s 0.1 to 300 with steps of 0.1
RP-32R
CONFIG - O, Trip, Alarm
INHIBIT - O or On
THRESHOLD %Pn 4.0 to 15.0 with steps of 0.5
TIME s 0.1 to 300 with steps of 0.1
UNBC-46
CONFIG - O, Trip, Alarm
INHIBIT - O or On
THRESHOLD % 2 to 90 with steps of 1
TIME s 0.5 to 60 with steps of 0.1
UNBV-47
CONFIG - O, Trip, Alarm
INHIBIT - O or On
THRESHOLD % 2 to 90 with steps of 1
TIME s 0.5 to 60 with steps of 0.1
Content of the ADVANCED PROTECTION menu
N.B.
Advanced protections are deactivated by default.
