Hallowell Acadia 024 - Table 14: Thermostat Settings

APPENDIX A - SETTINGS
41
Thermostat Settings
MENU
NUMBERS
FACTORY DEFAULT SETTING
CORRECT SETTING
DESCRIPTION
1
MS 2
HP 2
Select appropriate control style (2 stage heat pump)
2
(GAS)
ELE
Indoor blower control by furnace or thermostat
3
DAYS (7)
0
7 day, 5 day plus weekend, or 0 day no program
4
PS (4)
Program set points during each day
5
COOL OFF HEAT EMER
AUTO
COOL OFF HEAT EMER
AUTO
System switch (operating mode) with COOL, OFF,
HEAT, EMERGENCY, and AUTO change over.
6
E (ON)
Pre-Stage heating/cooling steps to reach desired
temperature at given time
7
Cr HEAT (FA)
SL
Cycle rate of heating mode (FA = Fast, SL = Slow)
8
Cr COOL (FA)
SL
Cycle rate of cooling mode (FA = Fast, SL = Slow)
9
Cr EMER (FA)
FA
Cycle rate of emergency heat mode
(FA = Fast, SL = Slow)
10
CL (OFF)
ON
Compressor lockout (5 Minute anti short-cycle)
11
dL (ON)
Customer Preference
Display Backlight
12
0
Pre-Calibrated
(Technician Adjustable)
Adjust display temperature to actual temperature if
verified to be different
13
°F
Customer Preference
Select °F or °C
14
b (ON)
Customer Preference
Keypad beeper on/off
15
HEAT (99)
80°F or LOWER
Heating mode upper limit
16
COOL (45)
65°F OR HIGHER
Cooling mode lower limit
17
KEYPAD LOCKOUT (L)
Customer Preference
Keypad Lockout Function
18
KEYPAD LOCKOUT (OFF)
Customer Preference
Turn Keypad Lockout on/off
19
FA HEAT (ON)
ON
Heat 2nd Stage Cycle Rate
20
FA COOL (ON)
ON
Cool 2nd Stage Cycle Rate
21
CHANGE FILTER (OFF)
ON
Selectable On or OFF
22
CHANGE FILTER
(725 hours) –
(about 1 Month)
Indoor air filter change timer (25-1975 hours)
25 Hour Steps
23
CHANGE HUMIDIFIER (OFF)
OFF
Selectable On or OFF
(If ON, hours are as described in the above selection.)
Table 14: Thermostat Settings
