Hallowell Acadia 024 - Appendix G - Specifications Sheet; SPECS a - Electrical and Physical Data

APPENDIX G – ACADIA SPECIFICATION SHEET
57
SPECS A
Electrical and Physical Specifications
Model
ACADIA024
ACADIA036
ACADIA048
Unit Supply Voltage
208/230-1-60
208/230-1-60
208/230-1-60
Normal Voltage Range
198-253
198-253
198-253
Minimum Circuit Ampacity
22.1 A
29.6 A
41.5 A
Max Over Current Device Amps
1
35 A
45 A
60 A
Min Over Current Device Amps
1
25 A
30 A
45 A
Primary Compressor Type (Multi-Stage)
T81J195CBCA
T81J285CBCA
T81J384CBCA
Compressor Amps (Primary)
Rated Load
4.9A 1cyl / 8.8A 2cyl
6.6A 1cyl / 12A 2cyl
7.5A 1cyl / 17.5A 2cyl
FLA / LRA
Locked Rotor
30A 1cyl / 65A 2cyl
39A 1cyl / 72A 2cyl
45A 1cyl / 105A 2cyl
Booster Compressor Type
H21J253ABCA
H21J343ABCA
H20J443ABCA
Compressor Amps (Booster)
Rated Load
10.4 A
13.1 A
17.3 A
FLA / LRA
Locked Rotor
61 A
78 A
102 A
Crankcase Heaters
18 W
18 W
18 W
Outdoor Fan Motor RLA
1.3 A
1.3 A
1.3 A
Fan Blade Diameter
22.125-in.
22.125-in.
22.125-in.
Outdoor Fan
Motor Power
1/4 HP
1/4 HP
1/4 HP
Motor RPM
850 RPM
850 RPM
850 RPM
Fan CFM
2712 CFM
2712 CFM
2712 CFM
Outdoor Coil
Face Area
14.33 sq ft
14.33 sq ft
17.5 sq ft
Rows Deep
2
2
2
Fins per Inch
20
20
20
Liquid Line OD (Field Installed)
3
3/8-in.
3/8-in.
3/8-in.
Vapor Line OD (Field Installed)
3
3/4-in.
7/8-in.
7/8-in.
R-410A Initial Charge
2
(Field Charge)
9 lbs
12 lbs  8.0 oz
12 lbs  8.0oz
Charge per ft of line set after 10ft
2
0.6 oz
0.6 oz
0.6 oz
Handling Weight
460 lbs
475 lbs
500 lbs
Matched Variable Speed Air Handler
AVG24B3XH21
AVG36C3XH21
AVG48D3XH21
Coil Model Number
373-23793-011
373-23793-002
373-23793-006
dBA Cooling and Heating (Mode 2 / Mode 3)
4
60/61
60/61
61/62
1. Use dual element fuses or HACR circuit breakers.
2. The system does NOT come pre-charged with R-410A refrigerant from the factory. The system comes from the factory with a 50 PSI charge of
nitrogen. After evacuation, systems with line sets of 10ft. or less receive 12 lbs  8.0 oz of liquid R-410A refrigerant. For line sets greater
than 10ft., add 0.6 oz of R-410A refrigerant for each additional foot.
3. The Acadia Systems require both the liquid and vapor lines to be insulated separately for maximum heating performance.
4. Sound pressure level re: 20µPA measured at 10ft. Noise levels were measured in an installed condition, in the field, with a Type 1 sound
level meter. These measurements are intended to be used in a precursory review; actual levels vary per each individual installation. Inquiries
and Concerns regarding specific applications should be reviewed by a qualified acoustical consultant.
(NOTE) All specifications are subject to change at the sole discretion of Hallowell International without notice and without inducing obligation
or liability.
