INSTALLATION DATA SHEET
62
Home Owner Information
Installer Information
Name
Company
Address Line 1
Address Line 1
Address Line 2
Address Line 2
City
City
State / Prov.
State / Prov.
Postal Code
Postal Code
Phone #
Phone #
Equipment Information
Acadia Outdoor Unit Model #
Acadia Outdoor Unit Serial #
Indoor Air Handler Model #
Indoor Air Hander Serial #
Indoor Coil Model #
Indoor Coil Serial #
Installation Information
Heat Kit Installed (Y/N)
Size of Heat Kit
Controller Program
(Invensys Control Board)
Economy Jumper
(Athena Control Board)
Total Line Set Length
Vacuum Achieved
Total R-410A Charge
Indoor Temperature

Outdoor Temperature

Temperature
Charging Port PSI
Sub-Cooling Amount
VOLTAGES NOT EXCEEDING 253VAC nor LESS THAN 198VAC
Line Voltage at ODU
Line Voltage at AHU
Primary Compressor Amperage
Booster Compressor Amperage (if applicable)
Start Winding (blue)
Start Winding (blue)
Run Winding (yellow)
Run Winding (black)
Common (red)
Common (red)
Total Amperage (L1)
Total Amperage (L2)
