28
Step 1. Locate the mounting holes for the landing gear on the
forward part of the bottom of the fuselage. They are located
immediately forward of the wing area. Using a hobby knife, cut
the film covering the holes.
Step 2. Trial fit the aluminum main landing gear over the holes
in the fuselage. If the holes do not line up exactly, use a 3/16′′
drill bit to drill out the proper hole location. Use the main gear as
the template.
Step 3. Using the hardware provided, mount the main landing
gear to the fuselage. Apply Blue Locktite 242 to secure the nuts.
• Fuselage
• Main aluminum landing gear
• Mounting hardware
• Drill
• 3/16′′ drill bit
• Hobby knife with #11 blade
• Medium Phillips screwdriver
• Felt tipped pen
• Blue Locktite 242
Parts Needed Tools and Adhesives Needed
Section 10: Installing the Main Landing Gear
