Step 5. Use radio packing foam (available at your local hobby
shop) when you install the receiver and battery pack. There is
ample room for the receiver and battery in the forward part of the
fuselage, in the area below the fuel tank. Wrap the battery and
receiver securely with foam and install them in the fuselage.
Step 6. Route the antenna back through the fuselage using an
antenna tube (not included), or route it outside the fuselage back
to the vertical fin. Install the switch on the left side of the
fuselage (typical installation).
Step 7. Hook up the servos and switch harness to the receiver
and battery pack as outlined in your radio’s instruction. Turn on
your transmitter and receiver to center the trims on your
transmitter. Turn off the receiver, then the transmitter, in that
order. Your servos should now be in their “electrical center”
position.
CONTINUED
Section 14: Installing the Radio
