6
2 Truck introduction
2.1 Application
This manual introduces the industrial truck is a four-wheel, tiller-operated electric stacker with a
folding operator platform, safety side arms and a steered drive wheel.
The industrial truck is designed for lifting and transporting goods on level floors. Wheel arm lift
increases the ground clearance when transporting goods on uneven surfaces. Loads can be
stacked or unstacked up to 5.5m high and transported over long distances. The rated capacity of
the truck is shown on the nameplate or the data capacity plate.
2.1.1 Truck models meaning
The rated capacity depends on the model. Users can get relevant information as rated load from
the product model.
Model Meaning
CDD Electric electric stacker
12,16 Rated capacity ×100kg
A Series
C1/Z3 Controller type
S Folding platform
L Initial lift
I lithium battery
The rated capacity does not generally match the permissible capacity. The capacity can be found
on the load chart attached to the rack.
