75
1.2 Motor
Traction motor
Traction motor is three phase AC motor, maintenance-free, but needs periodical check and clean.
When tighten the upper nut on the wiring board, lock the lower nut to avoid looseness, and the
suggested tightening torque is T=10.2Nm～12.4Nm.
Rated
power
kW
Rated
voltage
V
Rated
current
A
Max.
current
A
Rated
speed
r/min
Insulation
grade
Frequency
Hz
Quota
min
Temp.
℃
2.2 16 125 235 2985 H 103 S2-60 40
W V U
Speed sensor
Thermistor
Lifting bolt
