66
9.6 Removing the rear panel assy
Procedure:
– Park the truck securely.
– Fold out the safety arms and folding platform.
– Undo the four groups of bolts (58) on the rear panel assy (7) with a wrench.
– Lift the rear panel assy (7), remove it from the truck and place it securely next to the truck.
The panel is now disassembled.
Mounting is performed in reverse order.
7
58
58
WARNING
It’s prohibited to operating the truck with the rear panel assy removed.
When the rear panel was removed, before the repair, must to discharge (such as
controller) energy storage components.
