HANGCHA A Series - Dimension; Weight

36
5.2 Dimension / Weight
Item
1.2t-1.4t 1.6t
Length (L） mm 650 650
Width (W) mm 249 249
Height (H) mm 625 625
Min. allowable battery weight kg 200 260
Max. allowbabl battery weight kg 295 295
H
L
W
WARNING
 Battery weight and dimensions have considerable influence on operational safety of
the truck.
 When installing or replacing battery, be sure that battery in the fixed position.
