1.1.2 Dismount and assemble order
Dismount and disassemble the reduction box according to the following order:
－ Dismantle driving wheel (wheels);
－ Open oil discharging bolt and discharge the oil;
－ Disassemble swing bearing and top shell articles;
－ Disassemble driven cylindrical gear;
－ Open the cover, disassemble driven spiral bevel gear and output flange etc.
1.1.3 Notice to installment and use
－ Before installing, you should wipe the oil on the surface of the shell.
－ In case that the oil leaks during use, you are not allowed to dismount and disassemble the
product.
－ Prevent the assembling surface and exposed flange from being knocked or damaged,
otherwise it may influence the installment and use precision.
－ Working oil should keep clean, the new machine should change new oil in 50 hours for the
first use and every 1000 hours later.
－ Working oil should in accordance with brand no.(GL-5 85W/90).
1.1.4 Fault and troubleshooting
Fault Probably cause Method of Fault eliminating
Low efficient transmission and
overheat oil temperature
Lack of oil Add oil
Quantity of the oil is ineligible Replace
Gear or bearing is damaged Replace
Unstable running Gear or bearing is damaged Replace
Oil leakage
Wear or damage of oil seal Replace
Leakage from the gasket Screw bolt or replace
