HANGCHA A Series - Hydraulic System

89
2 Hydraulic system
Hydraulic system is mainly composed of hydraulic unit, lifting cylinder and rubber tube etc.
1
3
4
5
6
7
8
2
1. Hydraulic unit
2. Mounting bracket
3. Oil tube assembly
4. Oil tube assembly
5. Lifting cylinder
6. Oil tube assembly
7. Left lifting cylinder (mast lift)
8. Right lifting cylinder (mast lift)
Fig. 2-6 Hydraulic system
