6.2. PROBE
The HI7631233 four‑ring conductivity probe provides stable measurements over a wide measure range and
does not require frequent calibrations.
An integral temperature sensor measures temperature and adjusts the measured conductivity to a reference
temperature by applying compensation standards.
1
2
4
5
3
6
1 Cable
2 Probe body
3 Probe holes
4 Probe sensor
5 Plastic bung (remove for measurement and calibration)
6 DIN Connector
Functional & LCD Description 14
