Control Panels for X75 Systems Installation and Operation Manual 3
Chapter 1: Introduction and Installation
Front Views
Frame Mounted Local Control Panel
Figure 1-1 illustrates the front view of the frame-mounted X75HD/
X75SD local control panel.
Figure 1-1. Front View of the X75HD/X75SD Frame-Mounted Control Panel
X75-RCP Remote Control Panel
Figure 1-2 illustrates the front view of the X75-RCP Remote Control
Panel. The front panel of the X75-RCP does not include an interface for
SD removable media.
Figure 1-2. Front View of the X75-RCP
