Control Panels for X75 Systems Installation and Operation Manual 49
Chapter 2: Operation via Front Panel Controls
TSG (Test Signal Generator)
The X75HD/SD unit provides HDTV(8-bits) and SDTV(10-bits)
internal test signals. Table 2-9 on page 49 and Table 2-10 on page 50
respectively show the list of test signals for each standard, and these
options are directly accessible through the TSG button.The SD Keyer
and the test signals function share the same processing block.
Using the Keyer/TSG Insert parameter in Video Setup >
Processing > SD TSG & Slide, you can select a video source to be
processed by this block. All video output groups using the video input
source selected at the Keyer/TSG Insert parameter will automatically
have the Keyer/TSG inserted into their video processing paths.
Table 2-9. HDTV Test Signals
HD-SDI 1080 HD-SDI 720
Black Black
Color Bars 100% Color Bars 100%
Color Bars 75% Color Bars 75%
Color Bars 100% 4:3 Color Bars 100% 4:3
Horizontal Sweep Y-only Horizontal Sweep Y-only
Horizontal Sweep Horizontal Sweep
White White
10-Step 10-Step
5-Step 5-Step
Ramp Y-only Ramp Y-only
Ramp Ramp
Multiburst Y-only Multiburst Y-only
Multiburst Multiburst
Pluge Pluge
Aspect 4:3 Aspect 4:3
RP219-1 RP219-1
