Harris DA-DHR6804+D - Environmental and Power Specifications

Chapter 3
Operation
38
Copyright © 2010, Harris Corporation
Ch. 2 Slew Rate
 SD
 HD
 Auto
Controls output/rise fall time for
channel 2
 SD – Output Rise Fall time complies
with SMPTE 259M
 HD – Output Rise Fall time complies
with SMPTE 424M /292M
 Auto – Automatically selects proper
rise fall time based on incoming
signal
Parameter Hysteresis 0.1 second to 0.5 seconds Value used to determine how long a
condition (that is, signal presence)
must be asserted before it is reported
to the control system
Green Mode
 Enabled
 Disabled
Enables or disables the use of the
power-saving (“green”) mode
Out 1A Cable Fault [RO]
 Yes
 No
Reports loss of signal or termination
fault for the corresponding output
Out 1B Cable Fault [RO]
 Yes
 No
Reports loss of signal or termination
fault for the corresponding output
Out 1C Cable Fault [RO]
 Yes
 No
Reports loss of signal or termination
fault for the corresponding output
Out 1D Cable Fault [RO]
 Yes
 No
Reports loss of signal or termination
fault for the corresponding output
Out 2A Cable Fault [RO]
 Yes
 No
Reports loss of signal or termination
fault for the corresponding output
Out 2B Cable Fault [RO]
 Yes
 No
Reports loss of signal or termination
fault for the corresponding output
Out 2C Cable Fault [RO]
 Yes
 No
Reports loss of signal or termination
fault for the corresponding output
Out 2D Cable Fault [RO]
 Yes
 No
Reports loss of signal or termination
fault for the corresponding output
Ch.1 Data Rate [RO]
 Unknown
 270 Mb/s
 Bypass
 HD
 3G
Displays locked data rate for channel 1
Ch.2 Data Rate [RO]
 Unknown
 270 Mb/s
 Bypass
 HD
 3G
Displays locked data rate for channel 2
Table 3-5 DA-HRO6804+ Remotely Controlled Parameters (Continued)
Bold text = Default setting [RO] = Read only/feedback
Path Parameter Range Description
