DA-6804+D Series
Installation and Operation Manual
39
Copyright © 2010, Harris Corporation
Ch. 1 Re-Clocking Mode
 Auto
 270 Mb/s
 Bypass
 HD
 3G
Selects the reclock rate for channel 1
input
Ch. 2 Re-Clocking Mode
 Auto
 270 Mb/s
 Bypass
 HD
 3G
Selects the reclock rate for channel 2
input
Ch1 Loss of Lock Alarm
 Disabled
 Enabled
Enables or disables the Loss of Lock
alarm on channel 1 (the Loss of Lock
alarm indicates the signal is not
locked)
Ch2 Loss of Lock Alarm
 Disabled
 Enabled
Enables or disables the Loss of Lock
alarm on channel 2 (the Loss of Lock
alarm indicates the signal is not
locked)
SFP 1 Type [RO]
 Transceiver 1A
 Dual Receiver 1A
 Dual Transmitter 1A
 Unknown
 Transceiver 2A
 Dual Receiver 2A
 Dual Transmitter 2A
Displays the SFP type present in SFP
slot 1
Ch. 1 Rx Power [RO] 0.000 mW to 6.535 mW Internally measured receiver power on
optical channel 1
Table 3-5 DA-HRO6804+ Remotely Controlled Parameters (Continued)
Bold text = Default setting [RO] = Read only/feedback
Path Parameter Range Description
Table 3-6 DA-DHROE6804+ Remotely Controlled Parameters
Bold text = Default setting [RO] = Read only/feedback
Path Parameter Range Description
Processing Serial Number [RO] String Serial number for the module
License Key String License key number for the module
Other Output Config.
 Ch.1 1×8 with ACO
 Ch.1 1×8
 Ch.2 1×8
 2×4
Selects module output configuration
as dual 1×4 or 1×8, 1 input routed to
all outputs; or 1×8 with input 2 routed
to all outputs
Ch.1 Signal Present [RO]
 No
 Yes
Indicates if the input signal for
channel 1 is present or not
Ch.2 Signal Present [RO]
 No
 Yes
Indicates if the input signal for
channel 2 is present or not
Ch.1 Loss of Input Alarm
 Disabled
 Enabled
Enables or disables the Loss of Input
alarm for channel 1
