DA-6804+D Series
Installation and Operation Manual
41
Copyright © 2010, Harris Corporation
Out 2C Cable Fault [RO]
 Yes
 No
Reports loss of signal or termination
fault for the corresponding output
Out 2D Cable Fault [RO]
 Yes
 No
Reports loss of signal or termination
fault for the corresponding output
Ch.1 Data Rate [RO]
 Unknown
 270 Mb/s
 Bypass
 HD
 3G
Displays locked data rate for channel 1
Ch.2 Data Rate [RO]
 Unknown
 270 Mb/s
 Bypass
 HD
 3G
Displays locked data rate for channel 2
Ch. 1 Re-Clocking Mode
 Auto
 270 Mb/s
 Bypass
 HD
 3G
Selects the reclock rate for channel 1
input
Ch. 2 Re-Clocking Mode
 Auto
 270 Mb/s
 Bypass
 HD
 3G
Selects the reclock rate for channel 2
input
Ch1 Loss of Lock Alarm
 Disabled
 Enabled
Enables or disables the Loss of Lock
alarm on channel 1 (the Loss of Lock
alarm indicates the signal is not
locked)
Ch2 Loss of Lock Alarm
 Disabled
 Enabled
Enables or disables the Loss of Lock
alarm on channel 2 (the Loss of Lock
alarm indicates the signal is not
locked)
SFP 1 Type [RO]
 Transceiver 1A
 Dual Receiver 1A
 Dual Transmitter 1A
 Unknown
 Transceiver 2A
 Dual Receiver 2A
 Dual Transmitter 2A
Displays the SFP type present in SFP
slot 1
Ch. 1 Rx Power [RO] 0.000 mW to 6.535 mW Internally measured receiver power on
optical channel 1
Ch. 2 Rx Power [RO] 0.000 mW to 6.535 mW Internally measured receiver power on
optical channel 2
Table 3-6 DA-DHROE6804+ Remotely Controlled Parameters (Continued)
Bold text = Default setting [RO] = Read only/feedback
Path Parameter Range Description
