Chapter VI. Intake and exhaust systems
(a) Install a new exhaust manifold gasket to the cylinder head.
ÿ Every time after removing the exhaust manifold, the gasket
Note:
5. Surface damage
which is to be replaced.
Clue:
ÿ Install the pressure block with the beveled side towards the
cylinder head.
8. Installation of the pressure blocks of the exhaust manifold
(a) Check the exhaust manifold for cracks or deformation, and
scratches on the mating surface.
(a) Install the exhaust manifold clamp block onto the 4 double-
sided threaded studs.
(c) Fix the pressure block with 4 new exhaust manifold
mounting nuts (1-4).
6. Tightening the threaded stud (if the stud was removed
during disassembly)
ÿ Tightening torque: 22±2 Nm.
ÿ Pre-tightening torque: 15±2 Nm.
7. Installing a new exhaust manifold gasket
ÿ Tightening torque: 22±2 Nm.
(c) Use a torque wrench to ensure correct tightening torque.
29
Installation
Examination
