Chapter IX. Lubrication system
foreign particles.
4. Removing the oil pump
Not.
7. Checking the condition of the mesh filter. A clogged, cracked or damaged
filter must be replaced.
(a) Remove the 3 bolts (A and B) and remove the oil pump.
8. Check the condition of the sealing ring (B) of the oil receiver for deformation,
wear, damage, etc. and replace it if necessary.
ÿ Be careful not to scratch or damage mating surfaces during sealant removal.
comrade
5. Removing the upper part of the oil pan
(a) Remove the 13 bolts in reverse order as shown in the figure, and remove
the upper part of the oil pan.
9. Installation of the upper part of the oil pan
(a) Remove sealant.
(c) Gently tap the spatula with a rubber mallet to loosen the parts.
(1) Remove old sealant from mating surfaces.
6. Cleaning the strainer (A) of the oil receiver from
(2) Remove the old sealant from the edges of the bolt holes.
Note:
53
