Hawk Gladiator Manual

15
Commissioning
Gladiator Acoustic Switch Series
• Ensure system is mounted as suggested (see Mounting Dimensions & Instructions)
• Check where the actual level or target is relative to the sensors. Make sure that the material is not blocking
the path between the Transducers.
Blocked Chute Applications
Parameter Instruction
1. Set App Type
The system comes pre-set to Blocked Chute. To configure re-select the App
Type. You will be prompted to 'Re-Configure', Select 'Yes'.
2. Set Mode
Advanced or Standard. Advanced is recommended for Blocked Chute
applications.
3. Set ChuteWidth
You will be prompted to enter the width of the chute (this should also be the
distance between each Transducer face). An accurate value is critical to
system performance.
4. Set Back Chute Cutoff
The default Back Chute Cutoff Distance is +350mm (13.7") of the ChuteWidth
value. This parameter allows for additional refections to be accepted as a
good reading by the system.
6. Set Switch Point%
Set the Sensor Value% the unit must pass before triggering Relay 1. The
Default value is acceptable for most applications. It can be increased to
provide stability in difficult applications.
7. Set Relay Delay Timer Set the On and Off Delay timers for Relay 1.
8. RUN System Press RUN several times to commence unit operation.

Hawk Gladiator Specifications

Power

operating voltage	12-30VDC, 90-260VAC, 36-60VDC
power consumption	<0.8W @ 24VDC, <5VA @ 240Vac, <3VA @ 115Vac

Operating Environment

maximum operating pressure	2 BAR
operating temperature for remote electronics	-40°C (-40°F) to 80°C (176°F)
operating temperature for remote sensors	-20°C (-4°F) to 80°C (176°F)
enclosure sealing for remote electronics	IP67 (NEMA 4x)
enclosure sealing for remote sensors	IP68

Weight and Dimensions

transducer to amplifier separation	Up to 500m (1640ft)
typical weight for 15kHz transducer	8 kg
typical weight for remote amplifier	1 kg
