Hawk Gladiator Manual

Commissioning
Gladiator Acoustic Switch Series
16
•
Ensure system is mounted as suggested (see Mounting Dimensions & Instructions)
• Check where the actual level or target is relative to the sensors. Make sure that the material is not blocking
the path between the Transducers.
Level Switch Applications
Parameter Instruction
1. Set App Type Set App Type to 'Switch'.
2. Set Mode
Advanced or Standard. Advanced is recommended for Level Switch
applications.
2. Set Application Width
Set Start Distance and End Distance. This span should encompass the
distance to the opposing Transducer.
3. Set Sensitivity%
For simple / clean applications, set the unit to a high Sensitivity% value. For
difficult / dirty applications, set a low Sensitivity% value.
4. Set Switch Point%
Set the Sensor Value% the unit must pass before triggering Relay 1. The
Default value is acceptable for most applications. It can be increased to
provide stability in difficult applications.
4.Set Relay Delay Timer Set the On and Off Delay timers for Relay 1.
5. RUN System Press RUN several times to commence unit operation.

Hawk Gladiator Specifications

Power

operating voltage	12-30VDC, 90-260VAC, 36-60VDC
power consumption	<0.8W @ 24VDC, <5VA @ 240Vac, <3VA @ 115Vac

Operating Environment

maximum operating pressure	2 BAR
operating temperature for remote electronics	-40°C (-40°F) to 80°C (176°F)
operating temperature for remote sensors	-20°C (-4°F) to 80°C (176°F)
enclosure sealing for remote electronics	IP67 (NEMA 4x)
enclosure sealing for remote sensors	IP68

Weight and Dimensions

transducer to amplifier separation	Up to 500m (1640ft)
typical weight for 15kHz transducer	8 kg
typical weight for remote amplifier	1 kg
