Hawk Gladiator Manual

Specications
Gladiator Acoustic Switch Series
Operating Voltage
• 12-30VDC (residual ripple no greater than 100mV)
• 90-260VAC
• 36-60VDC.
Power Consumption
• <0.8W @ 24VDC • <6W @ 48VDC
• <5VA @ 240VAC • <3VA @ 115VAC.
Communications
• GosHawk, Modbus
• Multidrop mode can address 1-250 units over 4 wires.
Relay Outputs: (2) Remote
• Form ‘C’ (SPDT) contacts, rated 5A at 240VAC resistive
• Remote fail-safe test facility for one relay.
Operating Temperature
• Remote Electronics -40°C (-40°F) to 80°C (176°F)
• Remote Transducers -20°C (-4°F) to 80°C (176°F).
Fail-Safe
• Selectable - presence or absence of material.
Maximum Range
• Blocked Chutes:
Maximum: 15m (50ft)
Minimum: 400mm (32”).
Junction Box to Amplier Separation
• Up to 500m (1640ft) using specified extension cable
(Belden 3084A).
Junction Box to Transducer Separation
• Up to 30m (98.5ft) using specified extension cable
(Belden 3084A).
Maximum Operating Pressure
• 2 BAR.
Display
• 2 line x 12 character alphanumeric LCD
• Backlight standard.
Memory - Remote
• Non-Volatile (No backup battery required)
• >10 years data retention.
Enclosure Sealing
• Remote Electronics IP67 (NEMA 4x)
• Remote Sensors IP68
• Junction Box IP67.
Cable Entries
• 4 x 20mm (0.8”), 1 x 16mm (0.6”) knock outs.
• 1 x M20 Gland / 3/4” NPT threaded adapter.
Mounting
15kHz Blocked Chute
• Transducer 4” ANSI flange with decoupled thread piece
• Pipe Specification: 4-00” Z40 ID = 100mm Black Pipe
• Remote Amplifier Back mount, DIN rail mount.
Typical Weight kg lb
• 15kHz Transducer 8 17.6
• Remote Amplifier 1 2.2
All company or product names are registered trademarks or trademarks of their respective owners.
DOC-ACOUSTIC+ASC-MAN v2.0
0817
Hawk Measurement Systems
(Head Ofce)
15 - 17 Maurice Court
Nunawading VIC 3131, AUSTRALIA
Phone: +61 3 9873 4750
Fax: +61 3 9873 4538
info@hawk.com.au
Hawk Measurement
90 Glenn Street
Suite 100B, Lawrence, MA 01843, USA
Phone: +1 888 HAWKLEVEL (1-888-429-5538)
Phone: +1 978 304 3000
Fax: +1 978 304 1462
info@hawkmeasure.com
For more information and global representatives: www.hawkmeasure.com

Hawk Gladiator Specifications

Power

operating voltage	12-30VDC, 90-260VAC, 36-60VDC
power consumption	<0.8W @ 24VDC, <5VA @ 240Vac, <3VA @ 115Vac

Operating Environment

maximum operating pressure	2 BAR
operating temperature for remote electronics	-40°C (-40°F) to 80°C (176°F)
operating temperature for remote sensors	-20°C (-4°F) to 80°C (176°F)
enclosure sealing for remote electronics	IP67 (NEMA 4x)
enclosure sealing for remote sensors	IP68

Weight and Dimensions

transducer to amplifier separation	Up to 500m (1640ft)
typical weight for 15kHz transducer	8 kg
typical weight for remote amplifier	1 kg
