Hawk Gladiator Manual

18
Software
Gladiator Acoustic Switch Series
All units are programmed by default with Unlock Code 0 (zero). This can be adjusted in the Advanced menu.
Main Menus
Quickset Menu
Diagnostics
__mA
Normal or Recover or Failed
CAL
Level 2
Level 1
(Interface units only)
(Interface units only)
0.00%
R: 55%
Quickset
Advanced
0.00%
R: 55%
Quickset
Advanced
Unlock 0
CAL
Parameter Description Options
App Type
See 'Programming App Types' on next page for detailed
information.
• Blocked Chute
• Switch
Switch Point
Set Relay 1 trigger Sensor Value%. Default is 75%.
When the Sensor Value exceeds this % the unit will
commence the delay timer and then switches Relay 1.
• 1-99%
On Delay Relay 1 on delay timer. • Adjustable in seconds
Off Delay Relay 1 off delay timer. • Adjustable in seconds
Relay1 Action
Set default Relay 1 status. Failsafe High is Energized
(EN) during normal operations and De-energized (DEN)
when switches. Failsafe Low is De-energized (DEN)
during normal conditions and Energized (EN) when
switched.
• Failsafe High
• Failsafe Low
Lock Code Adjust system Unlock code. Default is 0. 0-200

Hawk Gladiator Specifications

Power

operating voltage	12-30VDC, 90-260VAC, 36-60VDC
power consumption	<0.8W @ 24VDC, <5VA @ 240Vac, <3VA @ 115Vac

Operating Environment

maximum operating pressure	2 BAR
operating temperature for remote electronics	-40°C (-40°F) to 80°C (176°F)
operating temperature for remote sensors	-20°C (-4°F) to 80°C (176°F)
enclosure sealing for remote electronics	IP67 (NEMA 4x)
enclosure sealing for remote sensors	IP68

Weight and Dimensions

transducer to amplifier separation	Up to 500m (1640ft)
typical weight for 15kHz transducer	8 kg
typical weight for remote amplifier	1 kg
