Relay 2 Functions
Gladiator Acoustic Switch Series
22
Relay 2 has several functions available to support the system & installation.
Relay 2 Functions
Parameter Description
Failsafe
Relay 2 is triggered in the event of a Failsafe condition. This includes insufficient input
voltage, missing / faulted Transducers, Corrupt communications between
Transducer / Amplifier and other general hardware faults.
Relay2 Mirrors Relay 1 functionality as level switch / alarm.
Maintenance Alarm
Relay 2 will be triggered when the Transducers Gain% value exceeds the
programmed value CleanGainHigh%.
Relay 2 will de-activate when Transducer Gain% alls below the programmed
CleanGainLow%.
Transducers using higher Gain% over time indicates that less signal is being received
and is a symptom of build up within the chute.
GainOptClean
Gain based Cleaning function triggers Relay 2 to activate the Acoustic Spray Cleaner.
When the Transducer Gain% exceeds the programmed CleanGainHigh% value
Relay 2 is triggered for the duration of 1/2 of the Relay 1 On Delay timer.
It will repeat the spray at the Clean Timer interval until the Transducer Gain% falls
below the programmed CleanGainLow% value.
Transducers using higher Gain% over time indicates that less signal is being received
and is a symptom of build up within the chute.
TimeOptClean
Time based Cleaning function triggers Relay 2 to activate the Acoustic Spray Cleaner.
Relay 2 is triggered for the duration of 1/2 of the Relay 1 On Delay timer and will
repeat at the selected interval for the selected duration.
