Hawk Gladiator Manual

Power Up Sequence
Gladiator Acoustic Switch Series
14
Powering The System For The First Time
Upon power up the system scrolls through system information including software revisions, model types,
serial numbers and device ID.
The first power up of an entirely new system will require Transducer Initialization.
See 'Transducer Initialization ' section for details.
After this sequence is complete the unit will begin pulsing and display Sensor Value% on the display.
The system is now ready for Commissioning.

Hawk Gladiator Specifications

Power

operating voltage	12-30VDC, 90-260VAC, 36-60VDC
power consumption	<0.8W @ 24VDC, <5VA @ 240Vac, <3VA @ 115Vac

Operating Environment

maximum operating pressure	2 BAR
operating temperature for remote electronics	-40°C (-40°F) to 80°C (176°F)
operating temperature for remote sensors	-20°C (-4°F) to 80°C (176°F)
enclosure sealing for remote electronics	IP67 (NEMA 4x)
enclosure sealing for remote sensors	IP68

Weight and Dimensions

transducer to amplifier separation	Up to 500m (1640ft)
typical weight for 15kHz transducer	8 kg
typical weight for remote amplifier	1 kg
