Hawk Gladiator Manual

Part Numbering / Specications
Gladiator Acoustic Switch Series
31
Water Pressure
• Maximum: 14bar (1400kpa)
• Minimum: 1bar (100kpa).
Water Quality
• System requires good water quality.
Install filter if required.
Solenoid coil MD-2-24VDC-PC - #549903
Feature Values
Assembly position Any
Switching position indicator No
Duty cycle 100%
Characteristic coil data 24V DC: 6,8W
Permissible voltage fluctuation +/- 10%
Protection class IP65
Ambient temperature -20...50
o
C
Max. tightening torque for fitting 0.5 Nm
Product weight 110 g
Electrical connection Per DIN EN 175301-803
Mounting type With knurled nut
Material information, solenoid coil Duroplast, Copper, Steel
Material information, coil Copper
GAWC-SYS1 cleaner package consists of
GAWC-X
GAWC-SL
GAWC-4P
GAWC-12MML
Z
GAWC-06MML
Z
Cleaning System (GAWC-SYS1) Cleaning System (GAWC-SYS2)
GAWC-SYS2 cleaner package consists of
GAWC-X
GAWC-SL2
GAWC-4P
GAWC-12MML
Z
GAWC-06MML
Z
Z
= specify pipe length in metres
FA4A- 4-ASC
Cleaning System Mounting Flange
Water Usage
• Approximately 200ml per second per transducer
(water pressure dependent).
Spray Cleaner Specications

Hawk Gladiator Specifications

Power

operating voltage	12-30VDC, 90-260VAC, 36-60VDC
power consumption	<0.8W @ 24VDC, <5VA @ 240Vac, <3VA @ 115Vac

Operating Environment

maximum operating pressure	2 BAR
operating temperature for remote electronics	-40°C (-40°F) to 80°C (176°F)
operating temperature for remote sensors	-20°C (-4°F) to 80°C (176°F)
enclosure sealing for remote electronics	IP67 (NEMA 4x)
enclosure sealing for remote sensors	IP68

Weight and Dimensions

transducer to amplifier separation	Up to 500m (1640ft)
typical weight for 15kHz transducer	8 kg
typical weight for remote amplifier	1 kg
