HBM C6A - Page 21

21
C6A
A0638−2.3 en/de/fr HBM
Maximum operating force
2)
F
G
% 150
Limit force
2)
F
L
% 150
Breaking force
2)
when used with hardened pressure pla-
tes
F
B
% u300
when used with load button ZL and
pendle bearing EPO3
% u300 u200
when used with spherical cap ZK % u200 u200
Static lateral limit force
1)
when used with hardened pressure pla-
tes
F
Q
% 20
when used with load button ZL and
pendle bearing EPO3
% 20
10
when used with spherical cap ZK % 10
Permissible vibration amplitude
1)
to DIN 50 100
F
rb
% 70
Nominal displacement without moun-
ting accessories ("15 %)
S
nom
mm 0.07 0.08 0.09 0.11 0.26
Natural frequency without coupled
ground and without mounting
accessories
F
G
kHz 4.5 8 6 7.5 4.3
Weight, without cable kg 1.4 1.7 10.8 12.2 33
Degree of protection to DIN EN 60 529 IP67
Cable length, 6−wire connection m 6
1)
The difference in tolerances when using different mounting accessories is due to the low overall height of
the transducer.
2)
By reference to nominal force
